| Casing material | Aluminum |
| Dimensions | 113mm x 84mm x 25mm |
| Weight | 272g |
| Ambient temperature | -10°C to +60°C |
| Humidity | 5% - 95% non-condensing |
| Power supply | 12Vdc, 2A via 230Vac adaptor |
| Interfaces | - 1x RS485
- 2x Digital input (5-50Vdc) suitable for S0 pulse counting
- 1x 12Vdc out, max. 60mA
- 2x Relay (max 1A, 50Vdc/30Vac)
- RJ45 gigabit ethernet
|
| Supported device types | - EV charging stations
- Energy meters
- Battery systems
- PV inverters
- Heat pumps and Switched loads
|
| Appliance class | IEC 61140 class III appliance |
| Pollution degree | IEC 60664 pollution degree 3 |
| Altitude | 0 – 2000m |
| IP rating | IP2X |
